| 生产厂家 / Manufacturer:
|
莱斯豪尔（Reishauer）
|
| 机床型号 / Machine model:
|
AZO
|
| 出厂日期 / Year of produce:
|
1980
|
| 机床编号 / Serial number:
|
52400-21
|
| 控制系统 / Control system:
|
Conventional
|
|
最小磨削齿根圆直径 / Min. root diameter:
|
10 mm
|
|
最大磨削齿顶圆直径 / Max. roof diameter:
|
330 mm
|
| 最大齿轮宽度 / Max. gear width:
|
180 mm
|
| 装夹范围 / Range of clamping:
|
145~420 mm
|
|
最大工件重量（含夹具） / Max.
workpiece weight (with fixture
|
)
~60 kg
|
| 齿数范围 / Range of teeth:
|
12~260
|
| 模数范围 / Range of modul:
|
0.5~6
|
| 最大螺旋角 / Max. helix angle (β):
|
±45°
|
| 砂轮直径 / Grinding wheel diameter:
|
270~350 mm
|
| 砂轮宽度 / Grinding wheel width:
|
62/84/104 mm
|
| 砂轮孔径 / Grinding wheel bore:
|
160 mm
|
| 主轴转速 / Spindle speed:
|
1900 rpm
|
|
工件每转进给 /
Workpiece feeding per rotation:
|
0.4~3.2 mm
|
|
工件每冲程砂轮进给 /
Grinding wheel feeding per workpiece st
|
0.01~0.08 mm
|
| 总进给 / Total infeed:
|
0.8 mm
|
|
工作电压和频率 /
Working voltage and frequency:
|
460 V / 60 Hz
|
| 总连接负载 / Total connecting power:
|
30 kVA
|
|
机床毛重 / Machine gross weight:
|
~5000 kg
|
|
机床外形尺寸 / Machine dimensions (L x W x H):
|
2990 x 2300 x 2100 mm
|
|
随机附件 / Peripheral equipments and accessories:
|
电控柜及全部线缆 / Electric cabinet and all connecting cables.
|
|
外置独立液压站 /
Standalone outlay hydraulic station.
|
|
油雾吸收装置 / Oil-mist exhauster.
|
|
冷却过滤有油箱 /
Coolant and filtration unit.
|
|
油冷机 / Oil chiller.
|
|
泵输送单元 / Pump transit unit.
|
|
AM10砂轮修整机 / AM10
wheel dressing machine.
|
|
Fassler DSA砂轮修整器 / Fassler DSA grinding wheel dresser.
|
