| 生产商 / Manufacturer:
|
德玛吉集团：吉迈特（Gildemeister）
|
| 型 号 / Machine Model:
|
MF Twin 65
|
|
年 份 / Year of Manufacturer:
|
1999
|
| 序列号 / Serial Number:
|
第1台： 4280001161
|
|
第2台： 4280001171
|
| 系 统 / Control system:
|
Siemens 840C
|
| 回转直径 / Swing diameter:
|
240 mm
|
| 车削直径 / Turning diameter:
|
200 mm
|
| 主轴距离 / Spindle distance:
|
800 mm
|
|
溜板1行程 / Slide 1 flat & length
travel:
|
199/555 mm
|
|
溜板2行程 / Slide 2
flat & length travel:
|
199/555 mm
|
|
主轴2行程 / Spindle 2 length travel:
|
600 mm
|
| ◤主轴1-左侧 / Spindle 1- Left:
|
|
| Chuck diameter:
|
200 mm
|
| Max. bar diameter:
|
65 mm
|
| Spindle bore:
|
79 mm
|
| Clamping tube inner diameter:
|
66 mm
|
| Front bearing diameter:
|
120 mm
|
| ◤主轴2-右侧 / Spindle 2 - Right:
|
|
| Chuck diameter:
|
200 mm
|
| Max. bar diameter:
|
42 mm
|
| Spindle bore:
|
56 mm
|
| Clamping tube inner diameter:
|
44 mm
|
| Front bearing diameter:
|
90 mm
|
|
◤主驱动器1-左侧 / Main Drive 1- Left:
|
|
| Max. drive power (40/100% ED):
|
28/21 kW
|
| Range of speed:
|
25~5000 rpm
|
| Max. drive torque (40/100% ED):
|
320/240 Nm
|
| C axis speed:
|
250 rpm
|
| C axis torque:
|
200 Nm
|
| Accuracy:
|
0.025 。
|
|
◤主驱动器2-右侧 / Main Drive 2
- Right:
|
|
| Max. drive power (40/100% ED):
|
18/14 kW
|
| Range of speed:
|
31~6300 rpm
|
| Max. drive torque (40/100% ED):
|
130/173 Nm
|
| C axis speed:
|
250 rpm
|
| C axis torque:
|
120 Nm
|
| Accuracy:
|
0.025 。
|
| ◤溜板1-上部 / Slide 1 - Upper:
|
|
| X/Z feed rate:
|
20/30 m/min
|
| Feed force:
|
400/700 daN
|
| Travel resolution:
|
0.001 mm
|
| Spindle pitch:
|
12x28/15x32 mm
|
| ◤溜板2-下部 / Slide 2 - Lower:
|
|
| X/Z feed rate:
|
20/30 m/min
|
| Feed force:
|
400/700 daN
|
| Travel resolution:
|
0.001 mm
|
| Spindle pitch:
|
12x28/15x32 mm
|
| ◤刀架1和2 / Tool Carrier 1 & 2:
|
|
| Capacity:
|
2 x 12
|
| Shaft diameter (DIN 69880):
|
30 mm
|
| Max. drive power (40/100% ED):
|
7/5 kW
|
| Max. drive torque (40/100% ED):
|
22/15 Nm
|
| Range of speed:
|
40~4200 rpm
|
|
外形尺寸（长x宽x高） / Dimensions
(L x W x H):
|
4770 x 2220 x 1950 mm
|
| 机床毛重 / Gross weight:
|
6500 kg
|
|
◤周边装置和附件 / Equipments and Accessories:
|
集成在主机上的电气柜 / Integrated electric cabinet.
|
| 卡盘或卡套 / Jaws for chucks.
|
| 排屑器 / Chip conveyors.
|
| 棒料器 / Bar feeders.
|
| 刀柄 / Tool holders.
|
|
动力刀座及其他 / Power tool seats and others.
|
| 技术资料 / Technical documents.
|
